- IW3631 0-10V調(diào)光 -
Features
- Integrated 0-10V Dimming Transformer Driver for 0-10V Dimming Systems
- Analog Dimming Input Pin – Wireless Dimming System Compatible
- Up to 90W Output Power
- High PF (> 0.95) and Low THD (< 10%) Over Entire Input Voltage Range and 50-100% Load Current
-
Flickerless? Technology
- Eliminates Virtually All LED Flicker
- < 5% Line Frequency Ripple on the Output
Features
- Fast Start-up Time (<0.5s)
-
Fully Protected
- LED Open/Short Circuit Protection
- Single Fault Protection
- Current Sense Resistor Short Protection
- Input Over-Voltage and Brown-Out Protection
- Junction Sensor Based Over-Temperature Protection
Applications
- 0-10V Dimmable LED Ballasts up to 90W
- Dimmable LED Ballasts with Analog Input up to 90W
- Wireless SSL Lighting Systems
